  • Hub oil seals and shaft oil seals which keep lubricated bearings which are regular replacement parts for logistic trucks.

  • Hub bearings of a truck support the entire weight of vehicle and play an important role in ensuring the smooth rotation of tires. The hub and shaft oil seals should be inspected and replaced periodically if the trucks are driven long distances. Since the hub and shaft oil seals are used at such locations, the possibility of deterioration and wear is that much higher. In case that the inside grease runs out or the hub bearing are damaged, and by this fire and other incidents occur, the truck will be unable to run. To prevent such a case, Musashi Oil Seal Mfg. Co.,Ltd. recommends not only the replacement of the shaft seals but also the hub seals simultaneously.
    • Front Wheel Seal

    • Rear Wheel Seal

    • Gasket

    • Front Wheel Seal

      Generally front wheel seals are those used in front hubs. They prevent leaks of grease oil in the bearing and also penetration of water and foreign substances from the outside.
      Vehicles using disc break generate dust of disc break. Front Wheel seals also prevent penetration of dust of disc break.

    • Rear Wheel Seal

      In general, most double tires equipped in truck vehicles have a hub seal (inner) and a shaft seal (outer).
      The hub seal prevents grease from leaking into the hub bearing and also prevents water and foreign substances from penetrating from the outside. They require press-fit when installing it.
      The shaft seal prevents leaks of hub bearing grease and also prevents differential oil from penetrating into the hub bearing. It does not necessarily require press-fit. It is strongly recommended that the hub seal (inner) and shaft seal (outer) be replaced at the same time.

    • Gasket

      A gasket is installed between the main body of wheel hub and hub cover (cap) to prevent leaks of bearing grease and also prevents water and foreign substances from penetrating from the outside.
      We offer a wide range of materials, from commonly used paper and non-asbestos materials to the latest materials with excellent serviceability, depending on the type of vehicle.
